4kW6kW/8kW/10kW/12kW/15kW/18kW A+++ Monobloc Heat Pump for Heating Cooling And DHW - Plus Series

· A+++ Energy class

· Heating+Cooling+DHW

· Low noise operation

· Environmental friendly

· Outlet water temperature up to 80℃

· Variable frequency coupled Heat Pump
Availability:

Floating Compressor Chamber — Quiet & Stable Operation

The independent floating compressor chamber is designed to physically isolate the compressor from the airflow and cabinet structure.

A six-point suspension system effectively absorbs vibration and reduces noise transmission, ensuring stable, quiet, and reliable operation even under demanding heating conditions.

Floating Compressor Chamber (1)

Heating+Cooling+DHW

The P series heat pumps offer a complete energy solution. They provide cooling, heating, and Domestic Hot Water (DHW). In winter, they keep your space warm. In summer, they cool it down quickly. They also supply 80°C domestic hot water. The system runs reliably, ensuring comfort and hot water year-round, no matter how extreme the weather. It balances convenience and efficiency.


Dual temperature zones



High Efficiency A+++ Energy Level

The P Series single-unit heat pump excels with its A+++ energy efficiency rating. This rating highlights its top energy-saving performance and leads in green heating solutions. A+++ significantly cuts carbon emissions, supporting the EU's goals for carbon neutrality and environmental sustainability. The P Series offers reliable heating, cooling, and hot water solutions for homes. It promotes an energy-efficient, comfortable, and smart lifestyle through outstanding performance. This makes it a perfect choice for those seeking high efficiency and sustainable development.


High efficiency A+++



Low Noise Operation -30dB(A)

The P series single-unit heat pump uses variable-frequency coupling to reduce noise from the fan and compressor. It adjusts speed and frequency to minimize vibrations and noise. This feature creates a quiet and comfortable living space. Users can enjoy peaceful nights, focused reading, or family gatherings without noise interference. This technology meets strict noise regulations and ensures a green, comfortable heating and cooling experience.


低噪音-P系列-1201


Output Water Temp. up to 80℃

The P Series single-unit heat pump uses advanced compressor and refrigerant technology. It delivers water temperatures up to 80°C. This boosts heating efficiency and heats water quickly for showers and baths. It also cools in summer, making it useful year-round. The Plus Series offers reliable high-temperature output. It pushes the limits of heat pump technology, providing comfort and cost savings for your home.


Outlet water temperature 80 degrees

Solareast Advanced Manufacturing Facilities


Solareast operates a 100,000 square meter manufacturing facility with an annual production capacity of 500,000 units. Our factory features 5 specialized assembly lines: 2 commercial heat pump lines, 2 water heater lines, and 1 household heat pump line.


With 85% self-manufactured components and newly established condenser & evaporator production lines plus copper pipe manufacturing, we maintain complete control from core components to finished systems. ISO 9001 certified operations ensure consistent quality and reliable delivery for global customers. Integrated manufacturing excellence delivering superior heat pump solutions worldwide.



Heat Pump Factory Diagram



FAQ

Q1: Is this heat pump suitable for both domestic hot water and space heating?

This unit is a highly integrated, multi-functional heat pump system meticulously engineered to efficiently deliver domestic hot water alongside indoor heating and cooling. It fulfils household hot water requirements for daily activities such as showering and washing, whilst providing an integrated solution for underfloor heating and cooling. This enables year-round comfortable temperature regulation, truly achieving one unit for multiple purposes.



Q2: Is this heat pump considered an eco-friendly and sustainable option?

This heat pump has achieved the EU's highest A+++ energy efficiency rating, strictly adhering to testing standards. It delivers top-tier energy efficiency performance in both low-temperature (35°C) and medium-temperature (55°C) applications. It significantly reduces energy consumption, providing an efficient and stable solution for whole-house heating, cooling, and domestic hot water. This enables users to substantially reduce energy costs and lower carbon emissions, demonstrating outstanding environmental and economic benefits.


Q3: Is this heat pump really that quiet?

Certainly. This heat pump product employs noise-reduction technology that couples the compressor and fan. Utilising advanced noise-reduction techniques, including hexagonal floating chambers combined with a two-stage vibration-isolation design, multi-layer composite high-efficiency sound-absorbing materials, and a thickened structure with a metal compressor sound-dampening chamber, it achieves comprehensive vibration dampening, sound absorption, and sound insulation. This ensures quiet and reliable operation.


Model


BLN-004TE1

BLN-006TE1

BLN-008TE1

BLN-012TE1

BLN-015TE1

BLN-018TE1

BLN-008TE3

BLN-012TE3

BLN-015TE3

BLN-018TE3

Power supply

V/Ph/Hz

220-240/1/50

380-415/3/50

Heating A7/W35

Rated Heating Capacity

kW

4.50

6.00

8.00

12.00

15.00

18.00

8.00

12.00

15.00

18.00

Rated Power Input

kW

0.84

1.19

1.50

2.52

2.99

3.79

1.53

2.55

3.02

3.82

COP

w/w

5.36

5.04

5.33

4.76

5.02

4.75

5.23

4.71

4.97

4.71

Heating A7/W55

Rated Heating Capacity

kW

4.50

6.00

8.00

12.00

15.00

18.00

8.00

12.00

15.00

18.00

Rated Power Input

kW

1.31

1.90

2.40

3.75

4.48

5.61

2.43

3.78

4.51

5.64

COP

w/w

3.44

3.16

3.33

3.20

3.35

3.21

3.29

3.17

3.33

3.19

Cooling A35/W7

Rated Heating Capacity

kW

4.00

6.00

8.00

11.80

14.50

16.00

8.00

11.80

14.50

16.00

Rated Power Input

kW

1.22

1.82

2.56

3.85

4.71

5.37

2.59

3.88

4.74

5.40

EER

w/w

3.28

3.30

3.13

3.06

3.08

2.98

3.09

3.04

3.06

2.96

Cooling A35/W18

Rated Heating Capacity

kW

4.10

6.00

9.80

11.80

16.00

18.00

9.80

11.80

16.00

18.00

Rated Power Input

kW

0.90

1.20

2.14

2.67

3.19

3.85

2.17

2.70

3.22

3.88

EER

w/w

4.56

5.00

4.58

4.43

5.02

4.68

4.52

4.38

4.97

4.64

SCOP

Average climate, W35°C

kWh/kWh

5.21

5.31

5.33

5.21

5.09

4.91

5.28

5.11

4.95

4.93

%

205

209

210

205

201

193

208

201

195194
/

A+++

Average climate, W55°C

kWh/kWh

3.93

3.93

3.97

3.99

4.03

3.99

3.90

3.99

3.95

3.90

%

154

154

156

157

158

157

153

157

155153
/A+++

Operating temperature range (heating mode)

Ambient temperature range

°C

-25~35

Water outlet temperature range

°C

20~80

Operating temperature range (cooling mode)

Ambient temperature range

°C

15~45

Water outlet temperature range

°C

5~25

Operating temperature range (hot water)

Ambient temperature range

°C

-25~45

Water tank temperature range

°C

20~70

ErP sound

power level


Average climate,

W35°C


dB(A)

50

49

5050545550505455

Average climate,

W55°C

dB(A)

51

505151555651515556

Sound

power level (1m)


Average climate,

W35°C


dB(A)

37

353535394035353940

Average climate,

W55°C

dB(A)

38

363636404136364041

Max. input power

kW

2.1

3.55.5

6.2

7.88.56.97.79.4

10.4

Max. input current

A

9

1524

27

343710111415

Refrigerant


TYPE/(GWP)

/R290(3)

Charged volume

kg

0.65

0.651.10

1.10

1.501.50

1.10

1.101.501.50

Water side connection

Inch

G1

G1-1/4

G1

G1-1/4

Water Pressure Drop

kPa

15

20

2515202025

Min/Max Water Pressure

MPa

0.1/0.3

Rated Water Flow

m3/h

0.77

1.00

1.40

2.06

2.58

3.10

1.40

2.06

2.58

3.10

Net Dimensions

( L*W*H )

mm

1100*438*660

1220*458*865

1320*478*913

1320*478*913

1187*488*1456

1187*488*1456

1320*478*913

1320*478*913

1187*488*1456

1187*488*1456

Packing dimensions (L*W*H)

mm

1155*485*806

1250*493*1010

1352*533*1055

1352*533*1055

1217*538*1598

1187*488*1456

1352*533*1055

1352*533*1055

1217*538*1598

1217*538*1598

Net Weight

kg

83

110

162

162

205

205169169212212
Gross weight

kg

98

125

182

182

225225189189232232
