Home » Product » Others-Heating And Cooling Heat Pump » All-in-One R32 Heat Pump – Cooling, Heating & Underfloor Heating System
This product is no longer available

All-in-One R32 Heat Pump – Cooling, Heating & Underfloor Heating System


·Seasonal SCOP Optimization for Year-Round Efficiency

· ErP A+++ Rated – Certified High-Efficiency Heating

· Low GWP & Zero ODP – Eco-Friendly Refrigerant System

· Sustainable Heating Solution with EU Efficiency Compliance

· Multi-Stage Heating for Variable Temperature Needs

· All-in-one design, quick setup, and reduced labor costs.

Availability:

Why Choose Solareast R32 Heat Pump?

Versatile Heating & Cooling System – Compatible with Multiple Heat Sources

Comprehensive Heating & Hot Water Solution

The Solareast R32 S Thermal B Series is a cost-effective and energy-efficient heating solution designed to work with various home heating systems.

✅ Compatible with multiple heating systems, including radiators, fan coils, baseboard heaters, and floor heating systems.
✅ Provides hot water for residential heating & sanitary water tanks, making it ideal for hot water systems.
✅ Advanced R32 refrigerant technology ensures high efficiency, reducing energy costs and heat losses.
✅ Optimized heat exchanger improves temperature control, delivering consistent warm air in cold climates.
✅ Compact & wall-mounted outdoor unit, minimizing installation costs and maximizing indoor space.



System diagram


Ultra-Quiet Operation

Whisper-Quiet Performance with Full DC Inverter Technology

The Solareast R32 S Thermal B Series operates at low noise levels, creating a comfortable home environment without disturbance.

✅ Noise level as low as 56dB(A) at 1 meter, reducing indoor air disturbances.
✅ Equipped with a full DC inverter Panasonic compressor & fan, optimizing airflow and minimizing operational noise.
✅ Smart speed control reduces vibrations, improving long-term performance and temperature control.
✅ Ideal for residential heating, offering a peaceful and energy-saving solution that lowers electrical energy consumption.

R32三联供-1m噪音


Environmentally Sustainable Refrigerant

Eco-Friendly R32 Refrigerant – A Greener Heating Solution

The Solareast R32 S Thermal B Series uses R32 refrigerant, which is more sustainable and energy-efficient compared to conventional fossil fuel heating systems.

✅ Lower Global Warming Potential (GWP) than R410A, reducing carbon footprint.
✅ Zero ozone depletion potential (ODP), ensuring a sustainable and eco-conscious heating solution.
✅ 30% less refrigerant charge required, improving system efficiency while lowering energy costs.
✅ Meets international energy regulations, promoting a low-carbon and high-efficiency heating alternative to gas furnaces.

r32 refrigerant VS r410A refrigerant


FAQ

1️⃣ What are the benefits of an R32 heat pump water heater?

Answer:

The R32 heat pump water heater provides high-efficiency space heating and cooling with lower energy consumption. Its advanced heat exchanger and optimized heat loss reduction ensure maximum energy savings, making it a cost-effective alternative to traditional gas furnaces and baseboard heaters.

2️⃣ How does an air source heat pump with electric resistance heating work?

Answer:

An air source heat pump extracts ambient heat from the air and efficiently transfers it indoors for heating. The electric resistance heating element provides additional backup heating, ensuring stable indoor temperatures in cold climate conditions while optimizing temperature control.

3️⃣ How does the R32 refrigerant contribute to environmental sustainability?

Answer:

The installation cost of an R32 heat pump is lower than traditional heating systems. Its compact and wall-mounted outdoor unit allows for easy installation and reduced labor costs. Over the long term, its higher energy efficiency and lower operating costs make it a cost-effective home heating solution.



Model:
BLN-006TB1BLN-010TB1BLN-014TB1BLN-018TB1
Power SupplyV/Ph/Hz220~240V/1/50220~240V/1/50220~240V/1/50

Nominal Heating (Max)

(A7/6℃,W30/35℃)

Heating CapacitykW2.50 ~ 8.304.20-12.205.30 ~ 16.506.20-20.50
Input PowerkW0.57 ~ 1.920.86 ~ 2.881.15 ~ 4.151.36 ~ 5.28
Current InputA2.53 ~  8.523.82 ~ 12.775.10  ~  18.416.10 ~  23.67
COPW/W4.32 ~ 5.864.23 ~ 5.393.97 ~ 5.433.88 ~ 5.21
Nominal Heating (Max)  (A7/6℃,W47/55℃)Heating CapacitykW2.30 ~ 7.623.85 ~ 11.204.90 ~ 15.106.30 ~ 19.90
Current InputkW0.75 ~ 2.611.13 ~ 3.751.65 ~ 5.251.65 ~ 6.82
Input CurrentA3.32 ~ 11.585.01 ~ 16.67.32 ~ 23.307.40 ~ 30.56
COPW/W2.92 ~ 3.332.99 ~ 3.462.87 ~ 3.382.91 ~ 3.34

Nominal Cooling  (Max)

(A35/24℃,W12/7℃)

Cooling CapacitykW1.80 ~ 7.102.60 ~ 10.304.50 ~ 13.505.50 ~ 17.50
Current InputkW0.61 ~ 2.430.91 ~ 3.651.45 ~ 4.851.65 ~ 6.25
Input CurrentA2.71 ~ 10.784.03 ~ 16.196.43 ~ 21.527.40 ~ 28.02
EERW/W3.0432.872.96
ERP Level(Outlet water temp. at 35℃)/A+++
ERP Level(Outlet water temp. at 55℃)/A++
Rated Input PowerkW2.713.836.207.50
Rated Input CurrentA121727.5035.00
Refrigerant Type / Charge / GWP../kgR32/1.25/675R32/1.8/675R32/2.8/675R32/3.5/675
Rated water flowm³h1.11.752.523.20
Fan quantity/1112
Fan motor type/DC inverter
Compressor/Panasonic / DC inverter / Rotary / EVI
Circulating pump/Inverter type / Built-in
IP Class/IPX4
Sound pressure at 1m distancedB(A)49525356
Max outlet water temperature°C60606060
Water piping connectionsinchG1G1G1-1/4G1-1/2
Pressure drop at rating water flowkPa25273032
Operating temperature range (Heating mode)°C-25~45
Operating temperature range (Cooing mode)°C16~45
Unpacked Dimensions ( L×D×H )mm1100*445*8501100*445*8501100*445*8501100*445*1450
Packed Dimensions  ( L×D×H )mm1160*530*10101160*530*10101160*565*10101170*530*1610
UnPacked Weightkg102107124151
Packed Weightkg114119136168
* Please refer to the nameplate for product upgrades or changes in specifications without prior notice.
